50082199 - SLSS 318M-S12 - Single beam safety device transmitter - Quad Industry GmbH

Àðòèêóë: 50082199
Íàèìåíîâàíèå: SLSS 318M-S12 - Single beam safety device transmitter
Ïðîèçâîäèòåëü: Leuze electronic


Part description SLSS 318M-S12 - Single beam safety device transmitter
Part no. 50082199



  • Technical features

    • Basic data
      • Series318
      • Operating principleOne-way principle
      • Device typeTransmitter
    • Characteristic parameters
      • Model2, IEC/EN 61496
      • MTTFd414 years, EN ISO 13849-1
      • Service life20 years, EN ISO 13849-1
      • Category2, EN ISO 13849
    • Optics
      • Operating range0 ... 10 m
      • Operating range limit0 ... 12 m
      • Light sourceLED, Red
      • LED light wavelength660 nm
      • Transmitted-signal shapePulsed
      • LED safety class1
    • Timing
      • Switching frequency1.000 Hz
      • Response time0.5 ms
    • Electrical equipment
      • Protective circuitTransient protection, Polarity reversal protection, Short circuit protected
      • Performance data
        • Supply voltage10 ... 30 V, DC
      • Inputs
        • Number of activation inputs1 Piece(s)
    • Connection
      • Number of connections1 Piece(s)
      • Connection 1
        • Type of connectionConnector
        • FunctionVoltage supply, Signal OUT
        • Thread sizeM12
        • Materialplastic
        • No. of pins4 Piece(s)
    • Mechanical data
      • Designcylinder
      • Thread sizeM18 x 1 mm
      • Dimension61.5 mm
      • Housing materialMetal, V2A
      • Lens cover materialplastic
      • Net weight60 g
      • Housing colorBlack, Silver
      • Type of fasteningScrew type
    • Operation and display
      • Type of displayLED
      • Number of LEDs1 Piece(s)
    • Environmental data
      • Ambient temperature, operation-25 ... 65 °C
      • Ambient temperature, storage-40 ... 70 °C
    • Certifications
      • Protection classIP 67
      • Safety classII
      • CertificationsCE, c UL US, TÃœV Nord
      • Standards appliedIEC 60947-5-2
    • Special design
      • Special designActivation input

  • Downloads

    • Part data of: 2013-11-24 21:03:00
